CAD/CAM Lab

3 D Printer: “Modular 3-In-1 3d Printer/Laser Engraver/CNC” Make: SNAPMAKER 2.0 A350T with Enclosure.

Hardware Configuration:

• IBM server X 3850M2, P/N 7141RA X 3850 M2, 2X XEON quad core, E7330,80W 24 GHZ/1066 MH2/6MBl2, 8X 1GB.
• Lenovo Think Centre MF79439 DP2 Core Duo 2.66 GHz, 1GB RAM, Dos, LENOVO 17” Think Vision TFT Monitor. Each workstation is equipped with USB keyboard and mouse, and housed in cabinets with SMPS for efficient power management.

Software Environment:

• Windows 10 Professional (64-bit)
• Utilities: Google Chrome, 7-Zip (64-bit), LibreOffice
• 82003 PTC PRO-Engineering, Perpetual Software version 4.0 (50)
• Ansys Academic Teaching Advanced. Version 12.1, 256000 Nodes (5)

Network:

• High-speed LAN connectivity to facilitate project collaboration and online research.

Lab Incharge Name: Dr. Parvez Waghoo

Lab Assistant: Mr. Usama Ansari

Material Testing Lab (MT LAB)

The Material Testing Lab is a fully air-conditioned facility equipped with modern equipment to facilitate practical exposure to evaluating the mechanical properties of engineering materials. Students perform experiments to determine properties like tensile strength, hardness, impact resistance, and fatigue behaviour. The lab helps in understanding material behaviour under various conditions, essential for safe and efficient design.

Key Features:

• Metavision polishing m/c,
• Trinocular metallurgical microscope,
• Metallurgical samples,
• Muffle furnace,
• Jominy end quench apparatus and Rockwell hardness tester.

Additional Facilities:

• Fully air-conditioned environment with ergonomic seating, whiteboards, and uninterrupted power backup for effective and uninterrupted sessions.

Lab Incharge Name: Prof. Pradeep Yadav.

Lab Assistant: Mr. Afzal Hunnary.

Mechatronics Lab

The Mechatronics Lab is a fully air-conditioned facility where sstudents work on sensors, actuators, microcontrollers, and PLCs to develop real-world automation solutions in clean air environment. The lab enhances interdisciplinary skills essential for modern industries like robotics, automotive, and manufacturing.

Key Features:

• Pneumatic trainer, Electro- Hydraulic trainer, PLC kit, Pick and Place Robot control module, PLC bottle filling plant, lift control module,
• Load/ Force measurement transducer, Temperature sensor transducer trainer,
• DC motor speed control using PID controller,
• Real time high temperature control of furnace using PID controller,
• Sensor trainer–Experimental Implementation of computer interfacing of sensors using Microcontroller.

Additional Facilities:

• Measuring pins.
• Plain Cylindrical Master.
• Thread Measuring Wire.
• Optical profile Projector.
• Dial Type Fiducial Indicator.
• Parkinson Gear Tester.
• Diameter of Gear: 100-200mm Max. Thickness of Gear: 30mm,
• Projector Magnification.
• Least Count of Lever Dial Guage: 0.01mm, Least Count of Dial Guage 0.01mm (Range 0-10mm), Vernier caliper. Digital Vernier caliper. Vernier Height gauge. Micrometer, Optical Flat

Lab Incharge Name: Prof. Shahab Dabir

Lab Assistant: Mr. Tausif Khan

Design Lab

The Design Lab is a fully air-conditioned facility. The lab nurtures creativity and technical skills essential for engineering design, manufacturing, and product development. The Design Engineering Lab focuses on developing innovative solutions through CAD, simulation, and prototyping tools for the Entrepreneurship Development & Product Design & Development Subjects to cater the need of new syllabus.

Key Features:
Computer Hardware: HP PRO 280G9, I7 12700 12C 2.10, 8 GB RAM, DDR4 256 GB, SSD 1 TB, HDD 7200RPM, SATA 6 G and Printing facilities.

Additional Facilities:
Fully air-conditioned environment with ergonomic seating, whiteboards, and uninterrupted power backup for effective and uninterrupted sessions.

Lab Incharge Name: Dr. S.S. Maghrabi

Lab Assistant: Mr. Tausif Khan

Heating Ventilation air Conditioning and Refrigeration Lab (HVAC Lab)

The HVAC Lab is a fully air-conditioned facility. The lab equips students with skills required for designing and analyzing energy-efficient thermal systems used in buildings and industries and provides practical knowledge of heating, ventilation, air-conditioning, and refrigeration systems. The HVAC & R Engineering Lab provide practical knowledge of heating, ventilation, air-conditioning, and refrigeration systems.

Key Features:

• Vapor Compression, Refrigeration Test Rig.
• Ice Plant Test Rig.
• Heat Pump Test Rig.
• General Cycle A/C Test Rig.
• Window A/C Test Rig.
• Vapor Absorption Test Rig.

Additional Facilities:
Fully air-conditioned environment with ergonomic seating, whiteboards, and uninterrupted power backup for effective and uninterrupted sessions.

Lab Incharge Name: Dr. Amey S. Wagh

Lab Assistant: Afzal Hunnary

Maintenance Engineering Lab

The Lab is fully air-conditioned facility. The lab is equipped modern equipment to impart practical knowledge of equipment maintenance, fault diagnosis, and reliability improvement. Students learn preventive, predictive, and corrective maintenance techniques for mechanical systems and machinery.

Key Features:
Multi-Function Rotor Experiment Bench

• Two oil-cup;
• Two balancing weight wheels (a thicker one & a thinner one);
• A DC-Motor: 0~10000rpm;
• A DC-motor-Power;
• Base of the Bench;
• Oil-Bearing-Supports
• A rotation shaft;
• A support of sliding bearing;
• Two supports for installing displacement sensors;
• An oil container;
• Some tools and screws 1 Damaged and 2 Good Ball bearing
• Bent Shaft
• Shims

Lab Incharge Name:Dr. Ashok Dhale

Lab Assistant: Mr. Usama Ansari

Central Workshop

The Workshop is located on the ground floor in the college building. The Engineering Workshop provides hands-on training in basic manufacturing processes like fitting, carpentry, welding, machining, and sheet metal work. It is equipped with essential tools and machines such as lathes, drilling machines, grinders, welding setups, and hand tools. The workshop develops fundamental technical skills, Hand on knowledge and practical understanding necessary for engineering applications and industrial practices in students.

Key Features:
Multi-Function Rotor Experiment Bench

• Lathe machine,
• shaping machine,
• Surface grinder,
• Tool and cutter grinder machine,
• Cylindrical grinder m/c,
• Universal Testing m/c,
• milling machine, Welding m/c,
• Rectifier welding m/c,
• Drilling machine,
• Power hacksaw,
• Spot welding machine,
• Grinding machine,
• CNC Milling machine,
• Surface plate,
• Lathe chuck keys,
• Vernier caliper,
• Safety goggle,
• Spanner set,
• Height gauge,
• Adjustable spanner, V-block,
• Allen key set,
• Smithy Furness,
• Leather hand gloves.

Lab Incharge Name:Prof. A. H. Jagtap

Lab Assistant: Mr. Dilip Ausarmal, Mr. Abdul Hameed

University top ranker from mech department

Mr. Ammar Ansari has secured first rank at the University of Mumbai, with a CGPI of 9.82, in Mechanical Engineering Examination for in academic year 2023-2024

Team SABOO VICTORS secured 1st position at ISTL (ISHRAE Student Technical League) organized by ISHRAE on 13th February 2020 in Mumbai.

Team SABOO VICTORS secured 1st position at ISTL (ISHRAE Student Technical League) organized by Indian Society of Heating, Refrigerating and Air Conditioning Engineers (ISHRAE) under the guidance of Prof. Shahab Dabir and Mr. Sandip Vardam as a mentor from industry on 13th February 2020 in Mumbai. Also above team got Best ISTL journey video award. There were 6 teams were qualified at Mumbai level in final round of ISTL. In the competition student members engage in technical challenges related to HVAC & Amp; R systems, often involving designing and analysing air conditioning systems for real-world scenarios, allowing them to apply theoretical knowledge in a practical setting; essentially a platform for students to showcase their technical skills within the HVAC field.
